Carli Backcountry 2.0 6-Inch Lift Suspension Kit for 2003–2013 Dodge Ram 2500 & 3500

Description

*This System is currently unavailable*

Carli’s 6″ Backcountry 2.0 system is designed for people seeking the best ride on and off-road on a budget. Utilizing Fox 2.0 Remote Reservoir Shocks, Carli developed a shock tune that delivers all around comfort and ride quality designed for on-road, in town, highway, towing/hauling as well as slow to mid speed off road use. The Fox 2.0s are hard-anodized, aluminum shocks that will stand the test of time, even when exposed to the elements. They’re constructed with bushings in the rod ends for long-lasting, maintenance free performance. This system was tuned and rides best with the full progressive leaf springs and 37’s with 17″ wheels.

*2010-present vehicles have 2 possible sizes of Sway Bar End Links. Place a socket on the nut that compresses the rubber End Link bushings; fitment of an 18mm socket will indicate the need for the 12mm part number.
**All Carli 6″ systems require the truck’s front driveshaft to be extended by 2 inches.
***Carli 6″ systems require a drop pitman arm. We provide a drop pitman arm as an option on this product page.

This system fits Dodge Ram 2500 and Dodge Ram 3500 4×4 trucks from 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013.
FEATURES
-Custom Carli Tuned Fox 2.0 Remote Reservoir Shocks
-Carli 6″ Multi-Rate Coil Springs
-Carli Fabricated Radius Arms
-5-Leaf Progressive Spring Pack (unless full progressive leaf spring option is selected)
-Zinc Plated U-Bolts
-Stainless Sway Bar End Links With F.K. Bearings
-Limit Straps
-Adjustable Track Bar
-Track Bar Drop Bracket
-Front Bump Stop Drops
-Rear Bump Stop Drops
-Reservoir Mounts
FITMENT GUIDE
Year Model Part Number
2012 DODGE RAM 2500/3500 4×4 Diesel (10mm End Links) CS-DBC20-6-12-D

2012 DODGE RAM 2500/3500 4×4 Diesel (12mm End Links) CS-DBC20-6-12-D-12mm2010-11 DODGE RAM 2500/3500 4×4 Diesel (10mm End Links) CS-DBC20-6-10-D2010-11 DODGE RAM 2500/3500 4×4 Diesel (12mm End Links) CS-DBC20-6-10-D-12mm

2003-09 DODGE RAM 2500/3500 4×4 Diesel CS-DBC20-6-03-D

Installation Instructions
