Carli 6″ Lift Suspension Kit for 2003–2013 Dodge Ram 2500 & 3500

Description

Carli’s 6″ Pintop 2.5 system is based off of Carli’s 6″ Performance 2.5 system with the exception of the fabricated shock towers. The 6″ Pintop 2.5 offers incredible on road ride quality as well as significantly improved off road performance. This system was tuned and rides best with the full progressive leaf springs and 17”/18” wheels on, 37” Toyo M/T at 40F/35R. Both of the aforementioned are strongly suggested.

This system will fit up to a 37” tire with the included Radius Arm System on 17”-18” wheels with 4.5” of backspacing.

*2010-present vehicles have 2 possible sizes of Sway Bar End Links. Place a socket on the nut that compresses the rubber End Link bushings; fitment of an 18mm socket will indicate the need for the 12mm part number.
**All Carli 6″ systems require the truck’s front driveshaft to be extended by 2 inches.
***Carli 6″ systems require a drop pitman arm. We provide a drop pitman arm as an option on this product page.

This system fits Dodge Ram 2500 and Dodge Ram 3500 4×4 trucks from 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013.
FEATURES
-Custom Carli Tuned Front Pintop King 2.5 Remote Reservoir Shocks
-Custom Carli Tuned Rear King 2.5 Piggyback Shocks
-Carli 6″ Multi-Rate Coil Springs
-Carli Fabricated Radius Arms
-5-Leaf Progressive Spring Pack (unless full progressive leaf spring option is selected)
-Zinc Plated U-Bolts
-Stainless Sway Bar End Links With F.K. Bearings
-Limit Straps
-Adjustable Track Bar
-Track Bar Drop Bracket
-Front Bump Stop Drops
-Rear Bump Stop Drops
-Reservoir Mounts
FITMENT GUIDE
Year Model Part Number
2012 DODGE RAM 2500/3500 4×4 Diesel (10mm End Links) CS-DPT25-6-12-D

2012 DODGE RAM 2500/3500 4×4 Diesel (12mm End Links) CS-DPT25-6-12-D-12mm2010-11 DODGE RAM 2500/3500 4×4 Diesel (10mm End Links) CS-DPT25-6-10-D2010-11 DODGE RAM 2500/3500 4×4 Diesel (12mm End Links) CS-DPT25-6-10-D-12mm

2003-09 DODGE RAM 2500/3500 4×4 Diesel CS-DPT25-6-03-D

Installation Instructions
